Experimental modal analysis

For our client needs experimental modal analysis was performed for eigenfrequencies identification and corresponding modal shapes for turbogenerator end-winding.

Scope of work:

  • Preparation of test instruction (if needed)
  • Conduction the measurement on site
  • Results analysis

Results:

  • Dynamic properties of analysed object.
